High Speed Single Jersey Open Width Circular Knitting Machine

The High Speed Single Jersey Open Width Circular Knitting Machine is specially designed for stretch fabric manufacturing. With synchronised winding and rolling, adjustable fabric spreader, and built-in safety stop motion, it delivers uniform fabric density across the full roll — from start to finish — making it the preferred choice for mills producing lycra and stretch-based fabrics at scale.

KEY SPECIFICATIONS

Technical Data

Model	Diameter	Gauge	Feeder	RPM
Open Width Machine	26" – 44" (3F per inch)	10-44 G	78-132 F	18–25 RPM

KEY FEATURES

Designed for Stretch Fabric at Scale

Special Take-Down Device

The special take-down device of the machine can fix the tension of the machine so as to extend the life time of the needles — reducing maintenance frequency and part replacement costs.

Uniform Fabric Density

Uniform fabric density is guaranteed in all parts of the fabric rolls, no matter in the start or the end of the fabric rolls — ensuring consistent GSM and finish throughout.

Scale with Record Function

This machine is equipped with scale so you can keep record when manufacturing. When producing the same specification fabric again, you can take the previous record as reference — saving setup time.

Adjustable Fabric Spreader

Adjustable fabric spreader is equipped with this machine so as to spread and adjust angles between the fabric roll and spreader according to the fabric features — adapting to different stretch levels.

Synchronised Winding & Rolling

Synchronous winding and rolling of the fabric ensures the fabric is rolled in uniform tension, avoiding uneven marks on the fabric — critical for stretch and lycra-based fabrics.

Easy Roll Removal

The roll of the take-down device is easy to take off when the winding and rolling is finished — reducing changeover time between rolls.

STANDARD EQUIPMENT

Included as Standard

Positive feeding units
Automatic lubrication device
Yarn feed stop motion, needle break detectors
Open width system
Automatic cleaning device
Yarn creel system

OPTIONAL EQUIPMENT

Available on Request

Lycra kit
Lycra feeding units
Yarn input measuring device

Sample Showcase

Discover the vibrant results of Double Jersey Knitting Machine printing.

VERSATILE APPLICATIONS

What the High Speed Open Width Machine Produces

Stretch & Lycra Fabrics

The primary application — producing uniform lycra and stretch fabrics for sportswear, innerwear, and leggings at high speed.

Open-Width Knit for Cutting

Fabric produced in open-width format — ready for direct cutting without tubular opening, saving processing time and cost.

Performance & Activewear Fabric

High-speed production of lightweight stretch bases for athletic wear and performance garments.

Swimwear & Bodywear Base Fabric

Tight, uniform stretch fabric for swimwear, bodysuits, and close-fit garment applications.
